4 Post Lift 4.5T | DM450

Description:

• Ready for alignment. Rear sliding plates, front places for alignment turntables
• Hydraulic cylinder and steel rope action on all 4 columns
• Lowering solenoid valve
• Pneumatic locking system
• Anti toe trap
• Electric switch safety (leveling, steel rope cut, top limit)
• Pneumatic jacking beam as option

Technical data:

• Capacity: 5500 kg
• Maximum lift: 1830 mm
• Lifting time: 60s
• Height: 2220 mm
• Width: 3360 mm
• Power: 2.2 KW / 400 V / 3 PH / 50 Hz – 2.2 KW / 230 V / 1 PH / 50 Hz
• Total weight: 1400kg
